Hobbywing EZRUN MAX6 4985SL 1650KV Brushless Motor & ESC Set – 160A

Description

The Hobbywing EZRun MAX6 V3 Sensorless Brushless ESC & Motor Combo includes the 4985SL 1/7 scale, 1650kV motor and is a great option for high-end, aggressively powered 3S – 6S builds.

Motor

• Model: 4985SL-1650KV
• Pole: 4
• KV (No-load): 1650KV
• Resistance: 0.0053 Ω
• Current (No-load): 5.4 A
• Max. Output Power: 5700 W
• Current at the point of M.O.P: 160 A
• Motor Diameter: 49mm
• Motor Length: 86.5mm
• Shaft Diameter: 5.0mm
• Shaft Length: 21.5mm
• LiPo Cells: 3-6
• Weight: 587g (20.71oz)
• Applications: 1/6th & 1/7th RC Vehicles

ESC

• Continuous Current: 160A
• Peak Current:
• Peak Current:
• Peak Current: 1,050A
• Motor Type: Sensorless Brushless Motor
• Applications: 1/6th Touring Car, Buggy, Truggy and Truck
• Motor Limit: With 6S LiPo/18S NiMH: KV ≤1500 (5892 size motor); With 8S LiPo/24S NiMH: KV ≤1200 (5892 size motor)
• LiPo/NiMH Cells: 9-24S NiMH, 3-8S LiPo
• BEC Output: 6V/7.2V Switchable, Continuous Current of 6A (Switch-mode BEC)
• Cooling Fan: Powered by the stable BEC voltage of 6V/7.2V
• Connectors: Input End: None, Output End: Female 6.5mm Gold Connectors (pre-soldered onto the PCB of the speed controller)
• Size (LxWxH): 70x56x46.5mm
• Weight: 240g
• Programming Port: FAN /PRG Port
